Siemens MAG8000 meter settings
Ensure that the MAG8000 meter has the following settings:
Address = 1
Data baud rate: 9600
Parity: None
Stop-bits: 1
Pulse weight: 100L, 0.1kL or 0.00001ML (depending on the unit the meter is configured to measure in, both result in 100L/pulse)
Physical connection:
Route the cable into the MAG8000 register via a suitable cable gland ensuring a good seal.
The PCB supplied with the Outpost product connects as shown in the attached images and the wiring is as follows:
Red, blue and green cores of the Outpost cable connect to the 3-terminal connector on our PCB as follows:
MAGTx-OPRd- = Red core
GND = Green core
MAGRx-OPRt+ = Blue core
Black and white cores to Siemens data terminals:
White core = MAG8000 terminal 57
Black core = TMAG8000 terminal 58
